Introduction to I2C In this article Grinan Barrett introduces us to I2C. Grinan explains how I2C works, provides many useful links to information related to I2C and example Arduino code for a robot project where multiple Arduino boards are used for sensing and control. Grinan submitted this article to uCHobby as part of the uCHobby Giveaway program. What is I2C? I²C uses only two bidirectional open-drain lines, Serial Data (SDA) and Serial Clock (SCL), pulled up with resistors. Typical voltages used are +5 V or +3.3 V although systems with other, higher or lower, voltages are permitted. The I²C reference design has a 7-bit address space with 16 reserved addresses, so a maximum of 112 nodes can communicate on the same bus. The maximum number of nodes is limited by the address space, and also by the total bus capacitance of 400 pF, which restricts practical communication distances to a few meters. Wikipedia Definition What exactly does the I2C protocol and usage mean to the average robot builder? x=1 x=2 x=3 x=4
